GA-series general gravure ink for plastic laminated film is an alcohol-ester soluble made of polyurethane as its main resin, which is typically applicable to gravure printing on BOPP, PET and NY film.
I. Scope of Application
1. Applicable film:
BOPP film with surface tension ≥ dyn;PET film with surface tension ≥ 50dyn;NY film with surface tension ≥ 52dyn;Printing grade K coating film (including K cellophane);Printing grade PT cellophane film.
2. Applicable lamination process:
Suitable for the process of dry lamination, solvent-free lamination and PE-extrusion lamination; while not suitable for PP-extrusion lamination process.
Application Characteristics
1. Excellent printability, suitable for all kinds of gravure printing from low speed to high speed;
2. The printing residual solvents are extremely low, in line with environmental protection, safety, non-toxic and hygienic requirements.
Standard Color Notation
GA1002 Red GA1143 Golden Red GA1201 Scarlet GA1891 Peach
GA2003 Yellow GA2017 Orange GA3002 Blue GA4003 White
GA5002 Black GA6050 Green GA7045 Purple GA8002 Varnish
Printing Viscosity
| Printing speed | Above 200m/min | 100-200m/min | Below 100m/min | |
| Printing Viscosity / Zahn Cup #3 | Colors | 13±1s | 13.5±1s | 14±1s |
| White | 12.5±1s | 13±1s | 13.5±1s | |
â ¤. Dilution Solvent Ratio
1. The dilution solvent reference ratio for white ink
| Type | Ethyl acetate | N-propyl acetate | Isopropyl alcohol |
| Quick-drying | 70 | 20 | 10 |
| Normal-drying | 50 | 40 | 10 |
| Slow-drying | 20 | 70 | 10 |
2. The dilution solvent reference ratio for color ink
| Type | Ethyl acetate | N-propyl acetate | N-butyl acetate | Isopropyl alcohol |
| Quick-drying | 20 | 60 | — | 20 |
| normal-drying | — | 80 | — | 20 |
| Slow-drying | — | 40 | 40 | 20 |
Notice
1. In practical application, the performance of ink would be affected by the environmental temperature and humidity, printing facility and process, as well as plate making parameters, etc. Please adjust the dilution solvent according to the actual situation.
2. The amount of isopropyl alcohol shall not exceed 20% of the total dilution solvent.
3. Please refer to the instructions in the following appendix for the boiling resistance of GA-series primary ink. If the spot color ink is intended to be used for boiling resistant packaging, please consult our technical department.
4. Please use GP-Series Retort Gravure Ink for Plastic Laminated Film if applied for retort packaging (above 100 °C).
5. In general, curing agent is not required when printing on BOPP or PET substrate under the boiling condition of 100 °C/40 min. However, due to the different adhesive types and laminating conditions applied by various manufacturers, customers are requested to make necessary confirmation during application.
6. When printing on NY film, it is recommended to add the GA-07 Curing Agent in the background white ink as a supplement under the boiling condition of 100 °C/40 min, to obtain more stable bond strength. The amount of curing agent added is generally 3-4% of the original ink.
7. The products marked with "Infiltration" shall not be used for NY-base material, boiled products and solvent-free laminated products; otherwise color migration is likely to occur.
8. Please store the product in a cool and ventilated place away from direct sunlight.
Please contact with our technical department if any consultation requested or any abnormal situation encountered with.
Appendix: Boiling Resistance of GA-Series Ink
| Color | Model No. | BOPP film or PET film(Boiled at 100°C/40min) | NY film (Boiled at 100°C/40min) | Color | Model No. | BOPP film or PET film(Boiled at 100°C/40min) | NY film (Boiled at 100°C/40min) |
| Red | GA1002 | — | — | Black | GA5002 | — | — |
| GA1004 | — | — | GA5016 | — | — | ||
| Yellow | GA2002 | — | — | Green | GA6050 | — | — |
| GA2003 | — | — | Purple | GA7045 | — | — | |
| Transparent yellow | GA2061 | — | — | Orange | GA2017 | — | — |
| Blue | GA3001 | — | — | Peach | GA1891 | — | — |
| GA3002 | — | — | Gold or silver ink | GH-Series | — | — | |
| White | GA4002 | — | — | Varnish | GA8002 | — | — |
| GA4003 | — | — | |||||
| GA4015 | — | — | |||||
| GA4016 | — | — |
Notes: 1. In the table, "√" indicates applicable and "×" indicates not applicable.
2. Please consult our technical department for the application performance of other types of ink.
